Multi-level Access Platforms

01 / 06

Up and over the pipes

2 levels over a pipe run to reach two valves. Every piece is a standard part, so the same kit can be rebuilt elsewhere.

Scroll to see how it is built · drag to turn it round

02 / 06

Standard parts, bolted

Posts, channels and braces from a small set of standard parts: nothing is welded on site.

How is it possible at Allmarc?

Trumpf TruPunch 1000 CNC punchingCNC punching

Used here for: Standard parts, bolted

• CNC punching
• Among the first in Gujarat, 2018

All our machinery

Deratech 8 m tandem press brake8 m bending length

Used here for: Standard parts, bolted

• 8 m bending length
• Tandem technology

All our machinery

03 / 06

Grip-Strut decks

Single-piece planks up to 8 m, with no joints in the walking surface.

How is it possible at Allmarc?

Grip-Strut walkway automation linePunching, embossing, edge bending, shearing

Used here for: Grip-Strut decks

• Punching, embossing, edge bending, shearing
• Single-piece planks up to 8 m

All our machinery

04 / 06

Stairs and rails

Stairs up from both sides and between levels, from the same kit.

05 / 06

Nothing touches the pipes

The platform stands on its own feet; it does not load the pipework it crosses.

06 / 06

A kit of parts

Posts, frames, decks and stairs: every member numbered, match-marked and packed in erection sequence.
