Fall-Protection Anchor Structures

01 / 07

Over a tanker bay

Anyone on top of a tanker must be tied off. The system maker supplies the lifelines; we build the steel they hang from.

Scroll to see how it is built · drag to turn it round

02 / 07

Posts and arms

Cantilever posts and arms that reach over the vehicle, with knee braces to keep the arm stiff under a fall load.

How is it possible at Allmarc?

Robotic H-beam cutting and bevelling cellBeams up to 1,000 x 500 mm

Used here for: Posts and arms

• Beams up to 1,000 x 500 mm
• 12 m long, 50 mm thick
• Hypertherm XPR 300

All our machinery

Kotec newRun10DX CNC beam drilling lineH-beams up to 1,000 x 500 mm

Used here for: Posts and arms

Heavy profiles that need precise holes, where plasma cannot do the job: the lower structure and panel borders of a ground flare, and every bolted PEB and multi-storey frame.

• H-beams up to 1,000 x 500 mm
• Drills 3 faces in one pass
• Channels, angles and box sections

All our machinery

03 / 07

Rigid rail

An overhead rail the anchor trolleys run along, so the worker can move the length of the tanker.

04 / 07

Lifeline posts

Posts for a tensioned horizontal lifeline.

05 / 07

Davit anchors

A single-point davit for a fixed work position.

06 / 07

Sized to the vehicle

Heights and reach follow the vehicles that use the bay.

07 / 07

A kit of parts

Posts, arms, rail and anchors: every member numbered, match-marked and packed in erection sequence.
